Thermally Broken

Innovative and tailored for both new construction and renovation endeavors prioritising energy efficiency and visual appeal, the recently introduced W50TB steel window boasts slender sightlines and an impressive U-value as low as 1.4 W/m2k, contingent upon the chosen glazing unit. Engineered meticulously, the W50TB system comprises thermally broken steel sections meticulously crafted to echo the essence of traditional W20 steel windows. Distinguished by its thermally broken profile, the manufacturing process of W50TB steel windows diverges from conventional solid, hot-rolled steel section windows.

Introducing the W50TB steel window has expanded the array of solutions available to specifiers, particularly within the realm of new construction, where contemporary architectural excellence is paramount. Embodying all the advantages typically associated with steel windows—such as slim profiles, expansive glass panels, superior light diffusion, and ample ventilation—the W50TB offers remarkable adaptability.



Ferrofinestra

The FerroFinestra collection encompasses an assortment of steel window profiles crafted through hot-rolling, cold-forming, and laser welding techniques. Architects have historically favoured steel windows, particularly when seeking to imbue a building with distinctive character and overall visual appeal. The minimalist allure of solid hot-rolled steel profiles, coupled with their capacity to sculpt windows, stands unparalleled. Their sleek contours lend an air of weightlessness to the frames, accentuating the façade's transparency. Such elegance proves challenging to replicate with the bulkier profiles characteristic of alternative materials.

In its truest essence, the FerroFinestra W50 TB system captures the captivating style of the 1930s. Enhanced by an innovative high-density polyurethane isolator for thermal insulation and the capacity to accommodate high-performance glazing, it seamlessly meets modern regulatory standards and comfort requirements. Additionally, its suitability for extreme weather conditions makes it an ideal choice where the conventional FerroFinestra might fall short.

Features of W50 TB

  • Cold-formed steel profiles crafted with precision, boasting a thickness of 1.5 mm.
  • Maintains the same sightlines and proportions as FerroFinestra W40.
  • Features the timeless 'stepped leg' design.
  • Equipped with mechanically fixed rebate gaskets.
  • Capable of accommodating double and triple glazing up to 37 mm.
  • Enhanced with high-density cast-in polyurethane isolator for optimal insulation.
  • Offers a selection of various glazing beads.
  • Compatible with 16 mm friction hinges.
  • Available with a diverse range of opening options.

Introducing the new W60 TB profile series, which seamlessly embodies the sleek, rational, and slender design ethos of the acclaimed FerroFinestra product family. With a profile depth limited to 60 mm, these profiles effortlessly accommodate energy-efficient insulating glazing up to 37 mm, striking a harmonious balance between design aesthetics and thermal performance. Leveraging an innovative fibreglass-reinforced polyamide insulator, they ensure exceptional insulation despite their compact profile design. This cutting-edge thermal barrier steel window system offers over 20 profiles across four steel finishes: steel, galvanized steel, Cor-Ten steel, and stainless steel (Aisi 316L).

The refined and graceful lines of the FerroFinestra W60 TB extend to the distinguished architectural bronze variant, known as BronzoFinestra W60 TB. This prestigious series caters to projects with the most exacting standards, elevating architectural excellence to new heights.

Presenting the FerroFinestra W75 TB system, renowned for its exceptional thermal insulation paired with sleek minimalist profiles, along with the added convenience of a tilt-and-turn opening mechanism. Available in a variety of finishes including bright steel, galvanized steel, Aisi 316L stainless steel, and Cor-Ten steel, the new FerroFinestra W75 TB boasts a profile depth of 75 mm, accommodating highly-efficient insulating glazing up to 52 mm. With a fibreglass-reinforced polyamide insulator ensuring top-notch thermal performance, this system is particularly suited for projects in regions with demanding climates and stringent energy-saving regulations.

In addition to the classic strip galvanizing option, we offer versions in bright steel (non-galvanised), Cor-Ten steel, and stainless steel (1.4404). Our diverse range is complemented by a wide selection of exclusive fittings and accessories meticulously recreated from original designs of the modern era. This comprehensive offering facilitates the realisation of various opening types for windows and doors, including tilt-and-turn windows, whether flush or overlapping in design.

Features of W75 TB

  • Tubular profiles with 1.5 mm thickness available in bright steel, galvanised steel, Cor-Ten steel, and stainless steel 1.4404.
  • Mechanically fixed rebate gaskets.
  • Extremely slender flush or overlapping sightlines.
  • Profiles designed to accommodate high-performance glazing.
  • High-performance thermal barrier for enhanced insulation.
  • Wide array of square and angular glazing beads.
  • Both visible and concealed hardware options.
  • Available with a diverse range of opening configurations.

Bronzofinestra

Bronze, an ancient metal, has been in use since the dawn of the Bronze Age over 5,000 years ago. Regarded as a 'living material,' it undergoes natural oxidation and weathering, displaying a spectrum of colors from copper red to golden yellow, ultimately settling into classic brown hues. Its inherent warmth sets it apart from other metals, emanating a distinct cosiness. In contemporary architecture, there's a renewed appreciation for the value and allure of this noble metal. In the 18th and 19th centuries, it stood as the primary choice for windows and doors in numerous iconic commercial buildings and residences, a testament to its enduring appeal.

Architectural bronze, a prestigious material tailored for FerroFinestra-designed profiles, is a copper alloy comprising approximately 58% copper, 40% zinc, and 2% other elements. Renowned for its remarkable physical attributes such as hardness, resilience, and ductility, it stands as an optimal choice for crafting windows and doors. As a 'living material,' architectural bronze undergoes natural oxidation over time, acquiring unique and captivating hues. Offering versatility, a wide range of openings is available, including tilt-and-turn, single-sash, and double-sash configurations, alongside side-hung and bottom-hung windows that can open inward or outward. Additionally, the system encompasses top-hung, vertical and horizontal pivoting windows, catering to diverse architectural needs.

Introducing the BronzoFinestra B60 TB, an embodiment of elegance and sophistication, mirroring the graceful lines of the FerroFinestra W60 TB. This distinguished series is meticulously crafted to meet the exacting standards of projects with the most discerning demands.

With the profile depth limited to 60 mm, the B60 TB profiles seamlessly accommodate energy-efficient insulating glazing up to 37 mm, striking a harmonious balance between design aesthetics and thermal performance. Leveraging an innovative fibreglass-reinforced polyamide insulator, these profiles ensure exceptional insulation despite their compact design.

The BronzoFinestra B60 TB expands the options of the thermal barrier steel window system, offering over 20 profiles across four steel finishes: steel, galvanised steel, Cor-Ten steel, and stainless steel (Aisi 316L).

Introducing the latest innovation from Ottostumm, the BronzoFinestra B75 TB system stands alongside the FerroFinestra W75 TB, marking a significant advancement. Architectural bronze, with its ever-evolving surface tones, imbues windows and doors with an unparalleled allure, adding timeless charm to any space.

With a profile depth of 75 mm, the system effortlessly accommodates highly energy-efficient insulating glazing up to 52 mm. Enhanced by a fibreglass-reinforced polyamide insulator, it ensures superior thermal insulation, rendering it ideal for projects in regions with stringent energy-saving regulations and challenging climates.

Complemented by a diverse range of exclusive fittings and accessories inspired by original modern designs, the profile facilitates various opening configurations, including tilt-and-turn windows, for both interior and exterior openings. The system offers options for flush or overlapping designs, providing flexibility to suit diverse architectural needs.

B75 TB

  • Solid extruded profiles
  • Mechanically fixed rebate gaskets
  • Extremely slender flush or overlapping sightlines
  • Profiles designed to accommodate high-performance glazing
  • High-performance thermal barrier
  • Wide array of accessories featuring visible and concealed hinges
  • Options for visible and concealed hardware

Lift and Slide Doors

The Lift&Slide thermal barrier sliding door systems excel in accommodating larger frame dimensions and weights, surpassing typical expectations. These profiles are crafted from steel, Cor-Ten steel, and marine-grade stainless steel (AISI 316L).

Introducing the MLS 72 TB Lift&Slide system, a fusion of steel's refined elegance with unparalleled thermal and sound insulation capabilities. Crafted from thick steel sheets and designed with precision, the profile's unique shape, coupled with advanced sealing systems, delivers exceptional performance. With thermal values ranking among the lowest in its class, the MLS 72 TB Lift&Slide is tailor-made for expansive openings with extraordinary dimensions and weight. Moreover, it seamlessly integrates with the latest home automation devices, enhancing convenience and functionality.

All profiles are meticulously cold-formed from 2mm thick steel, offering an optimal solution for large glazings weighing up to 600 kg. The 72 mm profile depth strikes a perfect balance between aesthetics and security. Its robust framing material accommodates security glass up to 50 mm thick and can be easily automated for added convenience.

Features of MLS72 TB

  • Tubular profile with 2 mm thickness, boasting extremely high moments of inertia.
  • Aesthetic cover cap equipped with insulating material.
  • Thermal barrier constructed from polyamide PA 6.6.
  • Insulated front strike for enhanced thermal performance.
  • Mechanically fixed rebate gaskets ensuring tight seals.
  • Profiles available in galvanised steel, Cor-Ten, and stainless steel AISI 316L variants.
  • Efficient water drainage system.
  • Profiles designed to accommodate high-performance glazing.
  • Wide selection of square and angular glazing beads.
  • Manual opening capability up to 400 kg and automated. opening up to 600 kg, supporting single and multiple sliding configurations, as well as pocket solutions.
  • Fittings equipped with concealed sliding mechanism for streamlined aesthetics.
